Specifications

• Dimensions

  add remove
  • Length:
    89.4 in
  • Overall width:
    33.1 in
  • Overall height:
    42.7 in
  • Seat height, unladen:
    30.1 in
  • Ground clearance:
    4.1 in
  • Rake (steering head):
    30
  • Trail:
    5.8 in
  • Wheelbase:
    59.8 in
  • Tires, front specifications:
    160/70TR17 73V
  • Tires, rear specifications:
    180/70R16 77V
  • Fuel Capacity:
    3.1 gal
  • Oil capacity:
    4.75 qt.
  • Weight, as shipped:
    487 lbs
  • Weight, in running order:
    502 lb
  • Tire, type:
    Dunlop® Harley-Davidson Series, radial
  • Fork angle:
    28
  • Reserve fuel capacity, fuel injection:
    0.8 gal
  • Coolant capacity:
    0.6 gal
  • Gross axle weight rating, front:
    359 lbs
  • Gross axle weight rating, rear:
    595 lbs
• Engine

  add remove
  • Engine:
    Revolution® Max 1250T
  • Bore:
    4.1 in
  • Stroke:
    2.8 in
  • Displacement:
    76.40 in³
  • Compression ratio:
    12.0:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1-into-2; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    92.9 ft-lb
  • Engine torque (RPM):
    6000
  • Horsepower:
    121 HP / 90 kW @ 7500 rpm
  • Lean angle, right (deg.):
    34
  • Lean angle, left (deg.):
    34
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    49 mpg (4.8 l/100km)
  • CO₂ emissions testing method:
    –
  • CO₂ emissions :
    –
• Powertrain

  add remove
  • Primary drive:
    Gear, 49/89 ratio
  • Gear ratios (overall) 1st:
    12.21
  • Gear ratios (overall) 2nd:
    9.022
  • Gear ratios (overall) 3rd:
    6.994
  • Gear ratios (overall) 4th:
    5.641
  • Gear ratios (overall) 5th:
    4.731
  • Gear Ratios (overall) 6th:
    4.131
• Chassis

  add remove
  • Front fork:
    43 mm inverted fork with compression, rebound and spring preload adjustability. Aluminum fork triple clamps.
  • Rear shocks:
    Linkage-mounted, piggyback monoshock with compression, rebound and hydraulic spring preload adjustability
  • Wheels, front type:
    Aluminum cast, satin black
  • Wheels, rear type:
    Aluminum cast, satin black
  • Brakes, type:
    Front: single rotor, floating, tower- mounted Rear: solid uniform expansion rotor
  • Brakes, caliper type:
    Front: radially mounted, monoblock, 4-piston caliper Rear: floating, single piston caliper
  • ABS:
    Standard
• Electric

  add remove
  • Gauges:
    4 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, musi
  • Battery:
    Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 12Ah, 225 CCA at 0°F
  • Charging:
    Three-phase, 45 Amp system (300 Watts @13 Volts, 1200 rpm, 585 Watts max power @ 13 Volts, 2250 rpm)
  • Starting:
    0.9 kW electric with direct drive starter motor engagement
  • Electric power outlet:
    USB C-Type , Output 5V at 2.4 Amp
• Infotainment

  add remove
  • Screen size:
    4 in (102 mm)
  • Type:
    Color TFT
  • Headset specifications (if equipped):
    Bluetooth
  • Languages:
    Arabic Chinese (Simplified/Traditional) Czech Danish Dutch English (default) Finnish French (Canada/France) German Greek Hungarian Italian Japanese Korean Norwegian Polish Portuguese (Portugal/Brazil) Indonesian Russian Slovak Spanish (Mexico/Spain) Swedi
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Headset function only
  • Vehicle information screen:
    TPMS, Engine temp, Battery Voltage, Ambient Air Temp
  • USB:
    Charging and Instrument update, USB-C, 5V, 3A
  • Bluetooth:
    Phone/Media Supported
